DJI FlyCart 100 (FC100) Heavy-Lift Cargo Drone

The DJI FlyCart 100 is a next-generation heavy-lift cargo drone engineered for demanding industrial, logistics and emergency-response missions — from transporting heavy equipment to remote worksites to delivering supplies in disaster or off-grid zones. With a massive payload capacity and robust, multi-sensor safety and delivery features (LiDAR, radar, vision systems), FlyCart 100 delivers a reliable aerial freight solution when trucks or helicopters are impractical. Its design supports both cargo-crate delivery and precision winch-based delivery — allowing safe, controlled placement of heavy loads in areas inaccessible to conventional vehicles. Whether used at construction sites, remote infrastructure projects, or emergency response operations, FlyCart 100 is built to carry heavy cargo safely and efficiently.

The DJI FlyCart 100 (FC100) is a purpose-built heavy-lift aerial logistics platform designed for industrial, infrastructure, and public safety delivery missions where conventional transport is unsafe, slow, or impossible.

With a 170 kg maximum takeoff weight, dual- or single-battery operation, IP55 environmental protection, and a multi-layer safety architecture (radar, LiDAR, vision, and parachute system), the FC100 enables controlled, repeatable cargo delivery in complex environments — including mountainous terrain, remote worksites, emergency response zones, and critical infrastructure corridors.

The FlyCart 100 supports both winch-based and fixed lifting systems, DJI O4 long-range transmission, RTK positioning, and ultra-fast battery turnaround, making it a viable platform for time-critical logistics and beyond-visual-line-of-sight (BVLOS) operations, subject to regulatory approval.

---

What’s in the Box

• DJI FlyCart 100 Aircraft (airframe)

• Safety System (radar, LiDAR, vision, FPV camera – integrated)

• Parachute System (E2MSF-100A)

• Remote Controller (TKPL 2)

• DJI Delivery App (software access)

• Documentation & safety materials

Not included (sold separately / optional):

• DJI DB2160 Intelligent Flight Batteries

• Winch System (A2EWH-100A)

• Lifting System (A2EDL-100A)

• C12000 Intelligent Power Supply

• D14000iE Generator

• D-RTK 3 Multifunctional Station

• Battery Incubator

---

Manufacturer Product Specifications

Aircraft

• Weight (without payload)

  • 55.2 kg (with lifting system)

  • 60.2 kg (with winch system)
    Excludes battery, cable, hook, and accessories

• Max Takeoff Weight: 170 kg
  (Restricted to 150 kg in select countries)

• Max Diagonal Wheelbase: 2330 mm

• Diagonal Length (tip-to-tip): 3904 mm

Dimensions

• Arms & props unfolded: 3220 × 3224 × 975 mm

• Arms folded, props unfolded: 1820 × 1840 × 975 mm

• Arms & props folded: 1105 × 1265 × 975 mm

• Folding Method: Arms fold toward aircraft body

• Battery Configuration: Single or dual battery
  Single-battery mode intended for emergency use

---

Flight Performance

• Max Flight Distance (<149.9 kg TOW)

  • Dual battery: 12 km

  • Single battery: 6 km

• Max Hover Endurance (<149.9 kg TOW)

  • Dual battery: 12 min

  • Single battery: 6 min

• Max Flight Time (<149.9 kg TOW)

  • Dual battery: 14 min

  • Single battery: 7 min

• Max Horizontal Speed: 20 m/s

• Max Ascent / Descent Speed: 5 m/s

• Max Flight Altitude: 6000 m (ASL, dual battery, no payload)

• Max Relative Altitude: 1500 m

• Max Wind Resistance: 12 m/s

---

Environmental

• Operating Temperature: -20 °C to 40 °C

• Ingress Protection: IP55
  Does not apply to propulsion system

---

Positioning & Navigation

• GNSS: GPS, Galileo, BeiDou, GLONASS

• Hovering Accuracy (RTK enabled):

  • ±10 cm horizontal / ±10 cm vertical

• Hovering Accuracy (RTK disabled):

  • ±60 cm horizontal / ±30 cm vertical

---

Propulsion System

• Configuration: Octocopter (8 motor pairs)

• Motor KV: 60 rpm/V

• Stator Size: 155 × 16 mm

• Propellers:

  • 62-inch carbon-fiber composite

  • Dual-blade folding design

---

Safety & Obstacle Sensing

• Front millimeter-wave radar

• Rear radar

• Downward radar

• LiDAR

• Quad-vision system

• FPV camera

Detection Range: ≤ 60 m
Radar Transmit Power: < 20 dBm

Note: System does not autonomously avoid moving objects. Cable and cargo collision avoidance is operator responsibility.

---

DJI O4 Video Transmission

• Max Transmission Distance:

  • FCC: 20 km

  • CE: 10 km

• Frequencies:

  • 2.4 GHz / 5.8 GHz (region dependent)

• Live View: 1080p / 30 fps

• Antenna: 4 antennas, 2T4R

• 4G Enhanced Transmission: Supported

---

Lighting System

• Direction: Forward & downward

• Max Power: 46 W

• Modes: Auto / Manual

---

Parachute System

• Model: E2MSF-100A

• Minimum Deployment Height: 100 m

• Touchdown Speed: ≤ 7 m/s

• Ingress Protection: IP55

• Activation: Manual & automatic

• Data Storage: Logs for 10 flights

---

Winch System (Optional)

• Model: A2EWH-100A

• Cable Length: 0–30 m

• Max Retraction Speed: 1.2 m/s

• Functions:

  • Load weighing

  • Auto balance

  • One-tap release/retraction

  • Emergency cable discard

---

Lifting System (Optional)

• Model: A2EDL-100A

• Cable Length: 10 m (recommended 10–15 m)

• Emergency Mode: Cable-cut escape

• Functions: Auto balance, weighing support

---

6 Key Features

1. 170 kg Maximum Takeoff Weight – Enables true heavy-lift aerial logistics

2. Dual-Battery Redundancy – Mission continuation and safety margin

3. Multi-Layer Safety Architecture – Radar, LiDAR, vision, and parachute

4. Winch & Fixed Lift Support – Flexible delivery profiles

5. IP55 Environmental Protection – Designed for harsh field conditions

6. Ultra-Fast Power Turnaround – 9-minute charging (with compatible power systems)

---

FAQs

Q1: How much does the DJI FlyCart 100 cost?
A: The DJI FlyCart 100 base aircraft starts at $16,617 CAD and is available to order through RMUS Canada. A typical FlyCart 100 configuration with winch and an additional battery is approximately $32,000 CAD, depending on final setup and requirements.

Mission-specific options can be added, including the winch system for $10,542 CAD, and DJI DB2160 Intelligent Flight Batteries for extended flight time and operational flexibility at $4,669 CAD per battery.

Contact us today to build a FlyCart 100 package tailored to your operational needs.

Q2: Is the FlyCart 100 approved for BVLOS operations?
A: BVLOS approval depends on national aviation authority regulations and operator certification. The FC100 is designed to support BVLOS-style missions, subject to regulatory authorization.

Q3: What industries use the DJI FlyCart 100?
A: Common applications include public safety logistics, emergency response, mining, energy, utilities, construction, and remote infrastructure support.
